Visualization

A definition you can read is a definition you can trust. Crucible renders any machine to two diagram formats with one method call each.

Two renderers

mermaid := m.ToMermaid() // GitHub-renderable stateDiagram-v2
dot := m.ToDOT()          // GraphViz DOT, for richer SVG output

ToMermaid produces a stateDiagram-v2 that renders inline on GitHub and in docs. ToDOT emits GraphViz DOT, better for large, deeply hierarchical machines where Mermaid grows unreadable, and for high-fidelity SVG on slides and docs sites. Both are deterministic: states keep their declared order, edges are sorted, so repeated calls are byte-identical and golden-stable.

Both renderers express the full structure: compound states nest, parallel regions render with dividers (Mermaid) or dashed clusters (DOT), final states draw their terminal marker, and owned states color-code by owner.

Options

The same variadic options tune either format:

m.ToMermaid(state.WithoutGuards())  // drop the [guard] suffixes
m.ToMermaid(state.WithoutOwners())  // drop owner color-coding
m.ToMermaid(state.LeftToRight())    // direction LR
m.ToDOT(state.TopToBottom())        // rankdir=TB

Same graph, code or JSON

Rendering is a pure function of the machine graph, the very structure the IR carries. A machine loaded with LoadFromJSON and re-quenched renders identically to one forged in code:

ir, _ := state.LoadFromJSON[Stage, Signal, Order](b)
m := ir.Provide(reg).Quench()
fmt.Println(m.ToMermaid()) // same diagram, byte for byte

A real diagram

The diagram below is generated at build time from fooddelivery.NewModel() via ToMermaid(), the same machine the example’s tests exercise, so it can never drift from the code:

stateDiagram-v2
    [*] --> Placed
    state Active {
        [*] --> Active_Fulfillment__Cooking
        Active_Fulfillment__Cooking
        Active_Fulfillment__AwaitingCourier
        Active_Fulfillment__EnRoute
        Active_Fulfillment__AwaitingCourier --> Active_Fulfillment__EnRoute: PickedUp
        Active_Fulfillment__Cooking --> Active_Fulfillment__AwaitingCourier: PlatedUp
        --
        [*] --> Active_Watchdog__OnTime
        Active_Watchdog__OnTime
        Active_Watchdog__Overdue
        Active_Watchdog__Overdue --> [*]
        Active_Watchdog__OnTime --> Active_Watchdog__Overdue: after(30m0s) SLABreached
    }
    Delivered --> [*]
    Canceled --> [*]
    Rejected --> [*]
    Active --> Refunding: Cancel
    Active --> Settling: DroppedOff
    Authorizing --> Active: Authorized [or(generousOrder,and(subtotal ge 5000,priority in ["fast","express"]))]
    Authorizing --> Rejected: Declined
    Placed --> Authorizing: Submit
    Refunding --> Canceled: Refunded
    Settling --> Delivered

These renderers power this very docs site: every embedded statechart is forged from a live machine, never hand-drawn. For the full lifecycle walkthrough behind the diagram, see the food-delivery example.
