Assigns

The context is your machine’s data: the order total, the held amount, the breach flag. The only place it changes is an assign: a pure reducer that takes the current context and returns the next one. Crucible uses value semantics, so a reducer receives a copy and yields a new value rather than mutating in place.

type AssignFn[C any] func(in state.AssignCtx[C]) C

func recordHold(in state.AssignCtx[Order]) Order {
    o := in.Entity        // a copy
    o.HeldAmount = o.Subtotal
    return o              // the next context
}

Register reducers by name, then reference them on a transition. Multiple Assign calls fold in declared order, each receiving the output of the previous:

reg.Assign("recordHold", recordHold)
reg.Assign("markBreached", markBreached)

// builder form is equivalent:
b.Reducer("settle", settleReducer)

Transition(Authorizing).On(Authorized).
    GoTo(Active).
    Assign("recordHold")

The AssignCtx carries the prior Entity, the triggering Event, and the ref’s static Params, so a reducer can fold event payloads into context (for example, folding a saga’s refunded amount in via the onDone event).

stateDiagram-v2
    direction LR
    Authorizing --> Active : Authorized / Assign(recordHold)
    note right of Active
        ctx_n+1 = recordHold(ctx_n, event)
        pure, by value, total
    end note

Keep assigns and actions distinct. An assign changes the machine’s own context. An action (Do) emits an effect for the host to perform IO. A reducer must stay total and side-effect free, with no IO, no errors, and no clock reads, because the engine may replay it during recovery or analysis. If you need the outside world to react, return an effect from a Do; if you need the data to advance, fold it in an Assign.
