Services

A service is asynchronous work scoped to a state: authorize a payment, run a cancellation saga, call an external API. Unlike an effect (fire-and-forget data the host dispatches), a service has a lifecycle: it starts when the state is entered, and its completion feeds back into the machine as an event.

Declare an invocation with Invoke, naming the service plus its onDone and onError events. The service is a context-aware function that may block and return a value or an error:

type ServiceFn[C any] func(ctx context.Context, in state.ServiceCtx[C]) (any, error)

reg.Service("authorize", authorizeFn)

b.State(Authorizing).
    Invoke("authorize", Authorized, Declined).
    Transition(Authorizing).On(Authorized).GoTo(Active).Assign("recordHold").
    Transition(Authorizing).On(Declined).GoTo(Rejected).Assign("recordDecline")

When authorizeFn returns successfully, the runtime fires the Authorized (onDone) event; its return value rides along as the event payload, so an assign on that transition can fold the authorized amount into context. A non-nil error fires Declined (onError) instead. If the state exits before the service finishes, its context.Context is cancelled, so services must honor cancellation.

stateDiagram-v2
    [*] --> Authorizing
    Authorizing --> Active : Authorized (onDone)
    Authorizing --> Rejected : Declined (onError)
    note right of Authorizing
        invoke "authorize"
        id = InvokeID("order", Authorizing, 0)
    end note

Each invocation has a stable identifier so the host can track and address it:

id := state.InvokeID("order", Authorizing, 0)

The arguments are the machine name, the originating state, and the invocation’s index on that state (zero-based, in case a state invokes several). That id is how you correlate a long-running call with the machine instance that launched it, and how the host knows which completion event to feed back.
